电压差分输入。
四个可调且可调用的内部指令值。
两个可调用的内部固定指令值。
电压控制输出。
通过象限识别选择斜坡时间。
工作电压极性反接保护。
01 | Command value and ramp cards, Analog, Euro-card format | VT-SWKA2-5 |
02 | Component series 10 ... 19 (10 ... 19: unchanged installation and connection dimensions) | 1X |
03 | Version: standard | V0 |
04 | Option: standard | 0 |
01 | 02 | 03 | 04 | |||
VT-SWKA2-5 | \u2012 | 1X | / | V0 | / | 0 |
Component series | 1X | ||
Material number | Data sheet | 1819929059 | |
Type of electronics | Analog | ||
Design | Euro-card | ||
Operating voltage | Nominal | UB | V | 24 |
Lower limit value | UB(t)min | V | 21 | |
Upper limit value | UB(t)max | V | 40 | |
Current consumption | max. | I | A | 0.35 |
Command value | Voltage | Differential input | Ue | V | \u200b0 \u2026 ±10 |
Differential input resistance | Re | kΩ | 100 | ||
callable, internally generated | Fixed value | V | 10 / -10 | ||
adjustable | V | 0 ... 10 or 0 ... -10 (reference potential is 0 V) |
Call-up internal potentiometer voltages | UE | V | 6 ... 40 (Ri = 2 kΩ, 4 inputs) | |
Ramp time combinations | high for α2 and β2 | 6 ... 40 (Ri = 2 kΩ) | ||
low for α1 and β1 | 695024 | |||
Ramp switch-off | UE | V | 6 ... 40 (Ri = 2 kΩ) | |
Voltage | Number and designation | 3 (signal outputs) | ||
Voltage 1) | U | V | \u200b0 \u2026 ±10 | |
| 1) | Imax = 10 mA |
Setting range 1 | Ramp time up/down | t | s | 0,05 \u2026 5 |
Setting range 2 | Ramp time up/down | t | s | 0,1 \u2026 10 |
LED display | Green 1 | Ramp combination α1/β1 | |
Green 2 | Ramp combination α2/β2 | ||
Yellow 1 | 4 command value call-ups P1 ... P4, 2 fixed values | ||
Red | Ramp off | ||
Green/Red | Green: UB ok, red: UB too low |
Anschlussart | 32-pin male connector, DIN 41612, form F | ||
Ambient temperature range | ϑ | °C | \u200b0 \u2026 \u200b70 |
Storage temperature range | ϑ | °C | -20 \u2026 \u200b70 |
Weight | m | kg | 0.33 |
Dimensions in mm
Dimensions in mm
仅允许在断电状态下拔出和插入放大器卡。
与天线线路、无线电设备及雷达系统之间必须保持足够距离（>1 m）。
电磁铁线及信号线不得敷设在动力电缆附近。
对于信号线和电磁铁导线，建议使用屏蔽电缆。
电缆屏蔽层必须尽可能短，并以大面积方式连接至控制柜。
阀电磁铁不得连接续流二极管或其他保护电路。
